Weather: What is a ‘gravity wave’?

This atmospheric phenomenon can rattle aircraft for miles around

March 1, 2017 By Jack Williams

Share via:

Atmospheric gravity waves may form when winds blow across mountains.

1. The wind blowing over a mountain pushes up a bubble of air.

3. The cooling of the air as it rises makes the air denser; the air’s ascent slows and it eventually begins sinking.

5. With the bubble of air now warmer and less dense than the surrounding air, the air begins rising again.

2. Momentum carries the bubble up, opposing the pull of gravity, after it cools below the temperature of the surrounding air.

4. As it sinks, gravity accelerates the downward motion. The air warms as it sinks.

6. The up-and-down motion continues, slowly dying as the wind carries the wave along.

Weather geek

Sometimes clouds outline gravity waves

Avoid these markers of where air masses meet:

Billow clouds usually occur where a layer of warm air is above a layer of cold air, as winds in the separate air masses are blowing in different directions.

To envision what happens, put the palms of your hands together with something round between them. Now, move your hands back and forth in opposite directions. The round object rolls, as does air between the layers that form billow clouds. Sometimes clouds show that the air is acting like ocean waves that break as they roll ashore on a beach.

You should avoid billow clouds by flying either well above or well below them, since the turbulence could be felt above or below them.

If you see billow clouds when you have a passenger, you could establish your geek cred by pointing out that you’re looking at “Kelvin-Helmholtz” clouds. The name honors the Scottish physicist Lord Kelvin and the German scientist Hermann von Helmholtz, who mathematically analyzed such waves in the nineteenth century. —JW

Flight instructor Gregory Bean described a strange weather encounter in an April 8, 2004, “Never Again” column on AOPA Online.

Bean says he “noticed no significant wind” on an April afternoon as he was preparing to take off from Burlington, Vermont. His weather briefing didn’t hint of any weather to worry about. Nevertheless, as he was preparing for takeoff, the airport’s automated terminal information service reported “winds from 140 degrees at 20 knots gusting to 35 knots with an altimeter setting of 29.74—pressure falling rapidly.” Pressure continued to drop; during his takeoff roll the controller said, “Altimeter 29.65!”

After takeoff, “The turbulence was as rough as I had ever encountered. My hand flailed wildly as I made the frequency change to Departure, and my eyeballs were rattling around as I tried to focus on my instruments,” Bean said. During the climb, “my altimeter wound up through 3,600 feet. The vertical speed indicator was pegged up.” After telling the controller he was coming back to land, “reading my instruments was hard enough, let alone reading a checklist! Thankfully my landing was uneventful.”

Bean had encountered a gravity wave. Gravity waves form on the boundary of fluids with different densities. Probably the most familiar gravity waves are those on top of a body of water. As wind blows against the water, it pushes some of it up. As the water rises, gravity pulls it down. Eventually gravity wins, but wind continues pushing the water, creating more waves.

In atmospheric gravity waves, the density differences are caused by different temperatures. Fortunately, atmospheric gravity waves don’t travel as far as ocean waves before they die out. Nevertheless, they can travel far from the disturbance that created them. For example, wind flowing over the Rocky Mountains sometimes creates gravity waves that are felt as turbulence by airliners high above Kansas.

Thunderstorms can cause gravity waves

Thunderstorms, like mountains, also create gravity waves as wind flows over them. One striking example occurred in June 1996, when Air Force One, with President Bill Clinton aboard, hit severe turbulence while flying 33,000 feet over the Texas Panhandle. Afterward, those eating in the press area said it looked like they had had a huge food fight. The investigation showed that wind blowing over a distant thunderstorm formed a gravity wave that shook Air Force One. —JW

Gravity waves aren’t ‘gravitational’ waves. The Oxford Dictionary of English defines gravity waves as “a hypothetical wave carrying gravitational energy, postulated by Albert Einstein to be emitted when a massive body is accelerated.” No, no, no, that definition is for a “gravitational wave.” Gravity waves aren’t difficult to imagine, especially when we have billow clouds to show us what they look like. One reason for the confusion, in addition to the similarity of the names, is that in February 2016 scientists announced they had found the first evidence that gravitational waves had been detected. Einstein’s idea was proven to be correct. —JW
