Overview

  • If the TBM 910 and 930 are the personal hot rods of the single-engine turboprop world, then Swiss manufacturer Pilatus’ PC–12NG is the stately multipurpose utility vehicle. With a huge cabin that can be set up in a roomy, six-place executive configuration, as an 11-seat high-density shuttle, or a seats-free strictly cargo hauler, the airplane appeals to a wide customer base—and its 1,400-plus sales prove it. Its forward airstair door, combined with a massive aft cargo door, allows operators to board even the largest loads. Fractional operator PlaneSense has a fleet of 35 PC–12NGs.

    Turbine Single-Pilot Directory

    Pilatus PC-12 NGX

    Pilatus PC-12

Specifications

  • Powerplant

    Pratt & Whitney Canada PT6A-67XP, 1,200 shp

  • Propellers

  • Length

    47 ft 3 in

  • Height

    14 ft

  • Wingspan

    53 ft 4 in

  • Wing Area

  • Wing loading

  • Power loading

  • Cabin Width

    5 ft

  • Empty Weight

  • Maximum gross weight

    10,450 lb

  • Useful load

  • Payload with full fuel

    988 lb

  • Fuel capacity

    2,704 lb

  • Baggage capacity

    40 cu ft

Performance

  • Takeoff distance ground roll

  • Takeoff distance over 50-ft obstacle

    2,485 ft

  • Rate of climb sea level

    1,920 fpm

  • Service ceiling

    30,000 ft

  • Landing distance over 50-ft obstacle

    2,170 ft

  • Landing distance ground roll

  • Cruise speed/endurance w/45-min rsv, std fuel (fuel consumption, ea engine) @ 75% power, best economy

    290 KTAS

  • Range

Limiting and Recommended Airspeeds

  • VX

  • VY

  • VNE

  • VS1

  • VSO

    67 KIAS

For more information, contact Pilatus at or via https://www.pilatus-aircraft.com/en/fly/pc-12

All specifications are based on manufacturer's calculations. All performance figures are based on standard day, standard atmosphere, sea level, gross weight conditions unless otherwise noted.
